MT150
Heavy-Duty Lift & Slide Door
A 150 mm heavy-duty lift-and-slide platform with six sealing lines and multiple track configurations.
Request project reviewSystem overview
Designed as a complete opening.
MT150 supports large door panels through reinforced profiles and full-system hardware. Two-track, three-track with screen, high-rail and low-rail options make it suitable for villas, hotels, offices and balcony enclosures.
- Six-line sealing structure
- 28 mm reinforced slim meeting stile
- High and low track options
- Integrated drainage track
Available specifications
- Frame width
- 150 mm two-track / 225 mm three-track
- Profile wall
- 2.2 mm
- Glass
- 5 + 20A + 5 or 5 + 27A + 5
- Thermal break
- PA66 polyamide
Final dimensions, performance and component selection are confirmed against the project drawings and local requirements.
